Works with your 2.5" Front and 3" Rear Fox Shocks
X3 Max RS Turbo RR W/ Smart Shocks
X3 Max X RS Turbo RR
X3 X RC Turbo RR 72
X3 X RS Turbo RR with Smart Shox X3
X RS Turbo RR
- Front Maximum Clearance* – 20.5”
•Rear Maximum Clearance* – 22.5”
• Front Minimum Clearance* – 4”
• Rear Minimum Clearance* – 4.5”
• Front Suspension Travel** – 16.5”
• Rear Suspension Travel** – 18”
• B Pillar roof to Ground* – 71” Maximum
• B Pillar roof to Ground* – 54” Minimum
* Factory Tire
** Factory travel numbers include "tire flex". We limit minimum clearance from the factory 1.4"/2.75" to 4"/4.5". Maximum extended is limited by the shocks so its the same as original.
• Air Spring Capacity up to additional 3,000 lbs. Cargo Capacity (Vehicle not rated for load)
• Approximately 120 lbs. for complete air system, Removal of factory coil springs reduces 57 lbs. for total additional weight of 63 lbs.
• 100% Bolt-in installation. No fabrication required
• Compressor/tank/valve/ECU mounts under seats
• Height based auto leveling system with 3 programmable presets.
• Will maintain height to account for change in weight
• Onboard air that can be used for service air. Fill Tires, Air Tools, etc.
Take your Can Am Max to the Next Level
8 - Air springs to convert your Factory Fox Shocks from Coil Spring to Air Springs
1 - Viair 485 Compressor
1 - Aluminum Air Tank
1 - Accuair VU4
1 - Accuair E-Level
1 - Height Sensor and Management Bracket Kit for no drill, bolt-on, under seat installation
1 - AN Hose & Fitting Kit
1 - Solenoid
